Karman S-ERGO ATX Active Wheelchair, 15.4 lb, 14″ to 18″ Seat, 275 lb | Ultra Lightweight Custom Performance Chair
$2,040.00
- Rated No. 1 in customer service
- Fast nationwide shipping, delivered to your door
- Manufacturer warranties
- Cash-back rewards on every order
Authorized dealer & provider · Huge selection · Questions? Call 585-505-6665
Karman S-ERGO ATX active wheelchair has a 15.4 lb aluminum frame built to order, an S-shape ergonomic seat in 14″ to 18″ widths and a 275 lb capacity, for active full-time users who want a light, tuned chair. Ships nationwide.
✔ 15.4 lb Aluminum Frame, Built to Your Order
✔ Patented S-Shape Ergonomic Seating Frame
✔ Adjustable Center of Gravity and Seat Height
✔ Back Angle 85°, 90° or 95°, Height 10.5″ to 15″
✔ 24″ Quick-Release Pneumatic Spoke Wheels
✔ 14″, 16″ or 18″ Seat, 275 lb Capacity
You earn -
Fast nationwide shipping, delivered to your door · 30-day returns on eligible products · Shipping & returns details
Share with Friends
- Description
- PRODUCT SPECIFICATION
- Shipping & Returns
- Product PDF downloads
- Reviews (0)
Description
Karman S-ERGO ATX Active Wheelchair, 15.4 lb Custom-Built Ultra Lightweight Performance Chair, 275 lb
The Karman S-ERGO ATX is an active wheelchair for people who push themselves all day and want a chair set up for their body, not an off-the-shelf frame. The 6061 T-6 aircraft-grade aluminum frame starts at 15.4 lb, and Karman adjusts every chair to the order specifications before it leaves the factory.
You choose the seat size, front and rear seat height, center of gravity, back height and angle, footplate height, casters and armrests. That build-to-order setup, a tension-adjustable seat and back, quick-release 24″ spoked rear wheels and a 275 lb capacity make it a true performance wheelchair for daily independence.
Not sure if an active, configured chair is the right type? Our most comfortable wheelchair guide matches the chair to how the user sits all day, and the Manual Wheelchair Knowledge Base explains seat width, depth, seat height and center of gravity before you choose your build.
Why Choose the Karman S-ERGO ATX Active Wheelchair?
Most folding wheelchairs are built to fit everyone a little. The ATX is built to fit one user well. Karman’s globally patented S-Shape seating frame follows the curve of the body to spread pressure and help keep the hips back in the seat, and the multi-geometry extruded cross bars keep the frame stiff, so more of each push goes into moving forward. Rear wheel position, back height and back angle let you trade quick handling and upper-body freedom for stability and support. It is a sporty wheelchair for everyday life, not a racing chair.
Who Is This Performance Wheelchair Best For?
The S-ERGO ATX is a good fit for:
- Full-time users who self-propel every day and feel the difference a lighter, stiffer frame makes
- Users who know their measurements or are working with a therapist on seat height, angle and balance
- People with cerebral palsy, MS, spinal cord injury or stroke who self-propel and benefit from a fitted, adjustable seat (a clinician should guide the setup; as a cerebral palsy wheelchair, its value is in the fit)
- Users up to 275 lb who fit a 14″, 16″ or 18″ wide seat
Choose something else if the user needs:
- A ready-to-ship ergonomic chair without a custom build: see the Karman S-ERGO 115 or S-ERGO 125
- An adjustable lightweight chair at a lower price: look at the Karman Flexx
- Mostly caregiver pushing, tilt or recline: compare options in the comfort guide
Karman S-ERGO ATX Specifications
| Model | Karman S-ERGO ATX (S-ATX) |
|---|---|
| Frame | 6061 T-6 aircraft-grade aluminum, patented S-Shape seating frame |
| Frame weight | 15.4 lb starting frame weight |
| Weight with standard options | 26 to 30 lb, depending on build |
| Weight capacity | 275 lb |
| Seat width | 14″, 16″ or 18″ |
| Seat depth | 16″ or 18″ (14″ x 15″ also offered) |
| Front seat height | 17″, 18″, 19″ or 20″ (5″ casters at 17″ to 18″, 6″ casters at 19″ to 20″) |
| Rear seat height | 16″ to 19″, set to order |
| Back post height | 10.5″ to 15″ |
| Back post angle | 85°, 90° or 95° |
| Center of gravity | Adjustable rear wheel position: stable, standard or active |
| Armrests | Flip-back, 8.5″ armrest height (or omitted for an active setup) |
| Footplate | One-piece folding footplate, height adjustable (14″ to 17″ seat to footplate), unlimited angle adjustment |
| Rear wheels | 24″ x 1″ quick-release pneumatic, 36 spoke |
| Front casters | 5″ x 1″ or 6″ x 1″ flat-free polyurethane |
| Push handles | None standard; fixed or folding handles optional |
| Overall open width | 21″ (14″ seat), 23″ (16″ seat), 25″ (18″ seat) |
| Folded width | 14″ |
| Overall length | 36″ |
| Overall height | 29″ to 38″, depending on seat height and options |
| Frame colors | Fashion White or Diamond Black, Aegis-treated high gloss metallic paint |
| Shipping box | 38″ L x 16″ W x 32″ H |
Sizing and Your Build
Start with seat width: measure across the hips while seated and add about 1″ to 2″. Seat depth should leave two to three fingers between the seat edge and the back of the knee. Lower seat heights give a stronger push; higher ones make transfers easier. A forward center of gravity feels lively but tips back more easily, so new users often start at the standard position. Some settings can be fine-tuned later; frame size and seat height are set when Karman builds the chair.
Comfort Upgrades and Accessories
The ATX ships with a tension-adjustable sling, which you can tighten where you need more support. Most daily users add a cushion: for pressure relief or positioning, see the Comfort Company cushions under Complete Your Chair below. The options above also include Frog Legs front fork suspension for a smoother ride outdoors. Caregivers who help on hills can add the Karman HD-9000 companion push handles, made for this chair.
Care and Maintenance
- Check rear tire pressure weekly; pneumatic tires roll best at the pressure printed on the sidewall
- Press the quick-release axle button and pull to check that each wheel is locked in place before you ride
- Wipe the frame and upholstery with mild soap and water; let the sling dry before folding
- Keep axles and caster forks free of hair and lint, and have the chair checked once a year
What’s Included
S-ERGO ATX frame built to your selected size, seat heights, center of gravity, back height and angle, casters, armrests and footplate; tension-adjustable seat and back upholstery; 24″ quick-release pneumatic rear wheels. Push handles, cushions, suspension and other accessories ship only if selected.
❓ Active Wheelchair FAQ
What is an active wheelchair?
A lightweight, adjustable manual wheelchair set up for a user who propels on their own every day. The frame is fitted to the body, so it rolls and turns with less effort than a standard folding chair.
How much does the Karman S-ERGO ATX weigh?
The frame starts at 15.4 lb. With standard options it weighs about 26 to 30 lb, depending on the build.
What is the weight capacity?
275 lb.
What seat sizes are available?
Seat widths of 14″, 16″ and 18″, with 16″ or 18″ depth, plus a 14″ x 15″ size. Choose your size in the options above.
Is it a good cerebral palsy wheelchair?
For users with cerebral palsy who self-propel, the fitted S-Shape seat and adjustable seat height, angle and balance can help with posture and control. Fit matters most, so plan the setup with a therapist or clinician.
Does the ATX fold?
Yes. It folds to 14″ wide, and the quick-release rear wheels come off for a smaller load in the car.
Can it be used outdoors?
Yes. The 24″ pneumatic rear tires absorb bumps, and Frog Legs suspension is optional.
Do you ship nationwide?
Yes, we ship the S-ERGO ATX nationwide as an authorized Karman dealer. Call 585-505-6665 for help choosing your build.
🔗 Wheelchair Guides, Answers & Tools
Want help choosing? Start with these guides, or call us at 585-505-6665.
👉 Most Comfortable Wheelchair (2026): 22 Picks by Need
👉 Manual Wheelchair Knowledge Base
👉 Manual Wheelchair Assessment Tool
👉 Home Medical Equipment Knowledge Base
👉 Browse Lightweight Wheelchairs
PRODUCT SPECIFICATION
| Specification | Details |
|---|---|
| Product Name | S-ERGO ATX Active Wheelchair |
| Category | Active / Ultralightweight Manual Wheelchair |
| Frame Material | 6061 T-6 Aircraft-Grade Aluminum |
| Frame Design | Multi-Geometrical Extruded Cross Bars (Rigid + Compact) |
| Frame Weight | 15.4 lbs (Starting Frame) |
| Total Weight | Approx. 26 – 30 lbs (Depending on Configuration) |
| Weight Capacity | 275 lbs |
| Seat Width Options | 14″ • 16″ • 18″ |
| Seat Depth Options | 16″ • 18″ (15″ for the 14″width) |
| Available Size Configurations | 14″ x 15″ 16″ x 16″ 16″ x 18″ 18″ x 16″ 18″ x 18″ |
| Front Seat Height | 17″ • 18″ • 19″ • 20″ |
| Rear Seat Height | 16″ • 17″ • 18″ • 19″ |
| Back Cane Height | Approx. 10.5″ – 15″ (Adjustable Range) |
| Back Cane Angle | 85° • 90° • 95° |
| Armrest Height | 8.5″ |
| Armrest Options | Flip-Back Armrests or Optional Removal |
| Footplate | One-Piece Foldable Footplate (Standard) |
| Footplate Adjustability | Height & Angle Adjustable (Unlimited Positioning) |
| Front Casters | 5″ or 6″ (Based on Seat Height Configuration) |
| Rear Wheels | 24″ Pneumatic 36-Spoke Quick Release Wheels |
| Center of Gravity | Adjustable (Performance vs Stability Tuning) |
| Seating System | Patented S-Shape Ergonomic Seating Frame |
| Seat & Back Sling | Tension Adjustable Upholstery |
| Overall Width | 21″ (14″ Seat) 23″ (16″ Seat) 25″ (18″ Seat) |
| Overall Height | 29″ – 38″ (Depends on Configuration) |
| Overall Length | 36″ |
| Folded Width | 14″ |
| Frame Colors | Fashion White • Diamond Black |
| Finish | Metallic Aegis Treated High Gloss Paint |
| HCPCS Code | K0005 / E1236 |
| Optional Upgrades | Frog Legs Front Suspension Upgraded Wheels (e.g., Spinergy) Custom Configuration Components |
| Warranty | Manufacturer Limited Warranty |
| Shipping Dimensions | 38″ L × 32″ H × 16″ W |
