Chariot IV Ultra Lightweight Wheelchair – Adjustable Lightweight Manual Wheelchair with Custom Fit & Comfort
$249.99
- Rated No. 1 in customer service
- Fast nationwide shipping, delivered to your door
- Manufacturer warranties
- Cash-back rewards on every order
Authorized dealer & provider · Huge selection · Questions? Call 585-505-6665
✔ 34 to 36 lb Folding Aluminum and Steel Frame
✔ 3-Position Axle: 20″, 19″ or 18″ Seat Height
✔ Seat Depth 16″ to 18″ with Extension
✔ Flip-Back Arms Adjust 10″ to 14″
✔ Quick-Release Rear Wheels
✔ 300 lb Capacity, 16″, 18″ or 20″ Seat
-
Fast nationwide shipping, delivered to your door · 30-day returns on eligible products · Shipping & returns details
Share with Friends
- Description
- PRODUCT SPECIFICATION
- Shipping & Returns
- Product PDF downloads
- Reviews (0)
Description
Proactive Medical Chariot IV Ultra Lightweight Wheelchair – 34 lb, 3-Position Axle, Seat Extension, Adjustable Arms, 300 lb
The Proactive Medical Chariot IV is an ultra lightweight wheelchair, as Proactive calls it, built on an aluminum and carbon steel frame with a black chip-proof finish that folds for storage. It weighs 34 to 36 lb, carries 300 lb on every seat width, and adjusts to the user in more ways than most everyday chairs.
Choose a 16″, 18″ or 20″ seat and swing-away footrests or elevating legrests in the options above. Every chair has removable flip-back padded arms that adjust from 10″ to 14″ high, a 2″ tool-free seat extension (16″ to 18″ deep) and 3-position quick-release rear axles.
Comparing chairs? Our most comfortable wheelchair guide shows where a lightweight manual wheelchair like the Chariot IV fits against transport, reclining and standard models, and the Manual Wheelchair Knowledge Base explains how to measure seat height, width and depth.
Why Choose the Chariot IV Lightweight Manual Wheelchair?
The Chariot IV is made to be fitted. Move the rear wheels between three axles to set the seat at 20″, 19″ or 18″ (or to angle the seat), add or remove the 2″ seat extension, set the arm height, raise or lower the wrap-around back upholstery, and adjust the height and angle of the front casters. The quick-release axles take the rear wheels off without tools, which makes the chair lighter to lift into a car, and the frame is designed to take custom backs and accessories later. For a fixed, lower-cost steel chair with a hemi seat, see the Chariot II hemi wheelchair; for full recline, the Chariot-RC recliner wheelchair; and for children, the Chariot IV XTC Pediatric.
Who Is This Ultra Lightweight Wheelchair Best For?
The Chariot IV is a good fit for:
- Users who want a lightweight manual wheelchair they can set to their own size
- Users who need a lower seat (18″ or 19″) to reach the floor with their feet
- Users who need side transfers (flip-back, removable arms)
- Caregivers who lift the chair into a car (quick-release rear wheels)
- Users up to 300 lb in a 16″, 18″ or 20″ seat
Choose something else if the user needs:
- The lightest possible folding chair, around 24 lb: see the Karman LT-980 and other lightweight wheelchairs
- A caregiver-pushed chair with small rear wheels: see transport chairs
- Recline for all-day sitting: see high back reclining wheelchairs
- A seat wider than 20″ or a capacity over 300 lb: see heavy duty wheelchairs
Chariot IV Wheelchair Specifications
| Model numbers | WCK416AHDASF / WCK418AHDASF / WCK420AHDASF (swing-away footrests); WCK416AHDAELR / WCK418AHDAELR / WCK420AHDAELR (elevating legrests) |
|---|---|
| Weight capacity | 300 lb (all widths) |
| Seat width | 16″, 18″ or 20″ |
| Seat depth | 16″, or 18″ with the removable seat extension |
| Seat to floor height | 20″; hemi 19″; triple 18″ (3-position axle) |
| Back height | 18″, adjustable-height wrap-around back upholstery |
| Overall width (with arms) | 24″ / 26″ / 28″ (16″ / 18″ / 20″ seat) |
| Chair weight | 34 / 35 / 36 lb (16″ / 18″ / 20″ seat) |
| Shipping weight | 40 / 41 / 42 lb |
| Arms | Removable, flip-back, padded; height adjusts 10″ to 14″ |
| Front rigging | Tool-free adjustable swing-away footrests with heel loops and composite footplates, or elevating legrests |
| Rear wheels | Quick-release on 3-position axles, polyurethane tires |
| Front casters | Composite, height and angle adjustable |
| Wheel locks | Push-to-lock |
| Frame | Aluminum and carbon steel, black chip-proof finish, folding |
| Upholstery | Nylon, with carry pouch |
Specs from Proactive Medical’s Chariot IV Wheelchair (K4) product page and product sheet.
Sizing and Fit
Measure across the hips while seated and add about 2″ for the seat width. Measure from the back of the hips to the back of the knee and subtract 2″ to 3″ for seat depth; 16″ to 18″ can be matched with the seat extension. Overall width is the seat width plus 8″ (24″, 26″ or 28″), so the 16″ and 18″ chairs fit most 28″ to 30″ doors. For foot propulsion, choose the 18″ or 19″ seat height.
Cushions and Accessories
The Chariot IV has a nylon sling seat, so most daily users add a cushion. For a Proactive Medical chair we recommend Proactive’s Protekt cushions first: the Protekt Supreme foam cushion, the Protekt Ultra Gel Seat Cushion for more pressure relief, and the Protekt Back Cushion (see Complete Your Chair below).
Care and Maintenance
- Wipe the nylon with mild soap and water and let it dry before folding
- Check that the quick-release axles click fully in and the wheel locks hold before each use
- After moving the axle, reset the caster height and angle so the chair sits level
- Follow the Proactive owner’s manual in the Product PDF downloads tab for adjustments
❓ Ultra Lightweight Wheelchair FAQ
How much does the Chariot IV weigh?
34 lb (16″), 35 lb (18″) or 36 lb (20″), per Proactive Medical.
Is the Chariot IV an ultra lightweight wheelchair?
Proactive calls it ultra-lightweight for an adjustable chair. If the lightest possible weight matters most, compare it with our sub-25 lb folding chairs, which have fewer adjustments.
What is the weight capacity?
300 lb on the 16″, 18″ and 20″ seats.
What seat heights can it be set to?
20″, 19″ (hemi) or 18″ (triple), using the 3-position quick-release axles.
Can the seat depth be adjusted?
Yes. A 2″ removable seat extension takes it from 16″ to 18″ without tools.
Do the arms flip back?
Yes. The padded arms flip back, come off, and adjust from 10″ to 14″ high.
Do you ship nationwide?
Yes, we ship the Chariot IV nationwide. Call 585-505-6665 for help setting it up.
🔗 Wheelchair Guides, Answers & Tools
Want help choosing? Start with these guides, or call us at 585-505-6665.
👉 Most Comfortable Wheelchair (2026): 22 Picks by Need
👉 Manual Wheelchair Knowledge Base
👉 Manual Wheelchair Assessment Tool
👉 Home Medical Equipment Knowledge Base
👉 Browse Lightweight Wheelchairs
👉 Best Lightweight Wheelchairs Guide
PRODUCT SPECIFICATION
📏 Product Specifications
| Product | Type | Weight Capacity | Seat Options | Chair Weight | Best Use |
|---|---|---|---|---|---|
| Chariot IV Ultra Lightweight Wheelchair | Adjustable Lightweight Manual Wheelchair | 300 lb | 16″, 18″, 20″ widths | 34–36 lb | Daily mobility, rehab, and customizable comfort |
- Frame Material: Aluminum & Carbon Steel
- Seat Width Options: 16″, 18″, 20″
- Seat Depth: 16″ (extends to 18″ with seat extension)
- Seat-to-Floor Height: 20″ (Standard), 19″ (Hemi), 18″ (Triple)
- Back Height: 18″
- Back Style: Adjustable wrap-around back with storage pouch
- Overall Width with Arms: 24″, 26″, 28″ (varies by seat width)
- Product Weight: 34–36 lb (depending on configuration)
- Shipping Weight: 40–42 lb
- Weight Capacity: 300 lb
- Rear Axle: 3-position adjustable (seat height & angle)
- Armrests: Flip-back, height-adjustable (10″–14″)
- Footrests: Swing-away removable (SWFR) or elevating leg rests (ELR)
- Footplates: Composite with heel loops
- Brakes: Push-to-lock wheel brakes
- Upholstery: Flame-retardant nylon, moisture & bacteria resistant
- Wheels: Composite mag-style rear wheels with polyurethane tires
- Casters: Solid front casters for smooth mobility
- Frame Type: Foldable for transport and storage
- Configurations: Multiple seat sizes, arm styles, and legrest options
- Warranty: Limited 3-Year Warranty
